Turnkey Solution Spray Tower Detergent Powder Production Line
Product Description
1. We can provide process design, equipment manufacturing, installation, commissioning and operation training for the washing powder production line of 5,000 to 250,000 tons/year.
2. Process configurations from simple manual operations to centralized automation of central computers can be designed. We also undertake technical consulting and old line engineering services. Adopt the process of high spray tower. Apparent specific gravity of product is 0.25~0.50g/cm3.All kinds of powder materials, liquid materials are weighed respectively according to the formula, , sent to slurry preparator to make slurry, after hydrated aging, crushing and filtering by aging system, sent to the top of spray tower by high pressure pump. Form mist particles through spray nozzles, dried by hot air generated by hot air furnace. At the bottom of the tower, hollow particles of detergent powder are formed. Then by air lifting, aging, base powder is made. After sieving, other materials (such as enzyme, color particles, essence, non-ionic, etc.) shall be added into base powder, and then put together into the post-blending mixer. After mixing and granulating, final detergent power in medium & top grade is made, and eventually packing.
Technology Characteristics
1. Equipment are durable, low cost of operation, easy maintenance;very light bulk density reached
200g/L-250g/L,high sprayed drying tower system.
2. Powder raw materials fed into tank in certain ratio automatically according to computer control
3. Distribute structure and multi-interface network ability easy to use.
4. Automatically controlled system which is suitable for large scale industrial control and visualization of the whole process of production
5. Semi-automatic and full automatic production line from 1T/hour to 30 T/hour
6. Workshop environment is provided with perfect dedustion system,ensure the workshop environment as clean as top level of Unilever,Henkel ,P&G
Product attributes
| Name | Turnkey Solution Spray Tower Detergent Powder Production Line |
| Application | Chemical Industry |
| Material | Stainless steel 304/316L |
| Usage | Detergent powder, washing powder |
| Capacity | ＞1 ton/hour |
| Heating method | Hot air furnace |
| Fuel | Oil, gas, coal, biomass |
| Machine Type | Automatic,semi-automatic |
| After-sales Service Provided | Engineers available to service machinery overseas |
